1.0 INTRODUCTION

This scaler Box is designed to display your analog video/YC//RGB images on HDTV’s with better viewing resolutions. It can upscale any SCART input source to HDMI output with a wide-range of resolutions. Incredibly, this device can also transfer sounds allowing everyone to enjoy both HD images and sounds.

2.0 FEATURES

1. Scales up SCART to HDTV resolution up to1080p;

2. Support input video systems NTSC/PAL/SECAM;

3. Digital Noise Reduction – Minimizes picture noise, reproducing images that   are true to the original;

4. Block Noise Reduction – Effectively minimizes all MPEG noise, Improving   the digital quality of HDTV broadcasts particularly, where block noise   happens most;

5. MPEG Noise Reduction – Reduce mosquito noise for MPEG video images   without losing detail;

6. 3D (frame based) motion adaptive noise reduction

7. Advanced 3D motion adaptive de-interlace

8. Automatic 2:2/3:2 film mode detection

3.0 PACKAGE CONTENTS

Before attempting to use this unit please check the packing and make sure the

following items are contained in the shipping carton:

(1)SCART TO HDMI Converter------------------1Pcs

(2)5V DC Power Supply---------------------------1Pcs

(3)User Manual--------------------------------------1Pcs

4.0 SPECIFICATIONS

Input ports------------------------------------------------------------------------1xSCART

Output ports------------------------------------------------------------------------1xHDMI

Dimensions(mm)------------------------------------------------100(D)x102(W)x25(H)

Wight (g)---------------------------------------------------------------------------------- 200

SCART input Format--------------------------------------PAL / NTSC3.58 / SECAM, NTSC4.43 /PAL-M / PAL-N

HDMI output resolution-----1080P50 Hz,1080P60 Hz,720P50 Hz,720P60 Hz,       800x600@60Hz,1024x768@60Hz,1280x1024@60Hz

Operating Temperature-----------------------------------0°C ~ 40°C / 32°F ~ 104°F

Storage Temperature-------------------------------------20°C ~ 60°C / -4°F ~ 140°F

elative Humidity-------------------------------------20 ~ 90% RH (Non-condensing)

Power Consumption (Max)------------------------------------------------------------3W

ESD Protection-----------------------------------------------------Human Body Model:

                                    ± 8kV (air-gap discharge)

                                    ± 4kV (contact discharge)
